RTJ2‑50/0.4(1.6)TB99Q Gas Pressure Regulator

Overview

This product is suitable for gas supply to residential communities, commercial and industrial users. It can be assembled into various types of pressure regulating boxes. Applicable media include natural gas, coal gas, liquefied petroleum gas, etc.

Features

Internal balancing valve, built‑in over‑pressure safety shut‑off valve with manual reset, safe and reliable.

Technical Parameters

Inlet Pressure Range P₁: 0.02‑0.4 MPa, 0.4‑1.6 MPa

Outlet Pressure Range P₂: 2‑200 kPa

Pressure Stabilization Accuracy Class: AC5, AC10

Lock‑up Pressure Class: SG10, SG15

Operating Temperature: -20℃‑60℃

Connection Nominal Diameter: DN50, PN16

RTJ2‑50/0.4TB99Q Flow Capacity Table (MPa)

Note: The flow values in the table are obtained under standard conditions with natural gas relative density of 0.6.

RTJ2‑50/1.6TB99Q Flow Capacity Table (MPa)

Note: The flow values in the table are obtained under standard conditions with natural gas relative density of 0.6.
