RTZ1-*/0.4A Series Direct Acting Gas Regulator
Get In Touch →Product Application
RTZ1‑*/0.4A Direct‑acting Spring‑loaded Regulator is mainly used for pressure reducing and stabilizing in residential district gas supply, direct‑fired units, gas‑fired boilers and large‑scale industrial furnaces.
Product Features
High flow capacity and precise control. Fast response speed, compatible with solenoid valves. Simple structure, convenient maintenance and on‑line maintainable.
Technical Parameters
Inlet Pressure: 0.02‑0.4 MPa
Outlet Pressure: 1‑5 kPa, 5‑30 kPa
Pressure Stabilization Accuracy Class: AC10, AC15
Lock‑up Pressure Class: SG20, SG25
Operating Temperature: -20℃‑60℃
Working Medium: natural gas, coal gas, liquefied petroleum gas, gas and other non‑corrosive gases.
RTZ1‑*/0.4A Regulator Overall Dimension Table
RTZ1‑*/0.4A Series Direct‑acting Gas Pressure Regulator
RTZ1‑50/0.4‑A Flow Capacity Table (MPa) (Diaphragm Housing φ330 for pressure above 0.005MPa)
Note: The flow values in the table are under standard conditions, with the relative density of natural gas being 0.6.
RTZ1‑80/0.4‑A Flow Capacity Table (MPa) (Diaphragm Housing φ330 for pressure above 0.005 MPa)
Note: The flow values in the table are under standard conditions, with the relative density of natural gas being 0.6.
RTZ1‑100/0.4‑A Flow Capacity Table (MPa) (Diaphragm Housing φ436 for pressure above 0.005 MPa)
Note: The flow values in the table are under standard conditions, with the relative density of natural gas being 0.6.
RTZ1‑150/0.4‑A Flow Capacity Table (MPa) (Diaphragm Housing φ436 for pressure above 0.005 MPa)
Note: The flow values in the table are under standard conditions, with the relative density of natural gas being 0.6.
RTZ1‑200/0.4‑A Flow Capacity Table (MPa) (Diaphragm Housing φ436 for pressure above 0.005 MPa)
Note: The flow values in the table are under standard conditions, with the relative density of natural gas being 0.6.
